Pinch Bottom Open Mouth

Ideal for dry products with varying densities.

Specs


  • Face: 9-23 in.​
  • Gusset: 2-7 in.​
  • Length: 20-50 in.​
  • Weight capacity: 10-50 lbs​
  • Closure: stepped-end heat sealed or easy open sewn​
  • Construction: up to 4 multiwall paper plies plus the option of a poly liner​
  • Printing: 8 colors




Options


  • Top or bottom ends can be flush cut for a sewn top or stepped for a foldable end with pre-applied hotmelt to reheat and seal for a hybrid SOM/PBOM bag design.​
  • High performance multiwall paper for additional strength and stretch.​
  • High barrier film options available for extra moisture or grease protection and extended shelf life.​
  • Over-all perforations on any ply for additional airflow​
  • Anti-skid​
  • Food grade metal detection




Advantages


  • Gussets and folded over ends allow for print areas on the top and bottom sections of the bag for branding artwork while the bags are packed and lying flat after being palletized ​
  • Flat bottoms and tops offer easy and stable palletization​
  • Ideal for automatic packing equipment




Overview


  • A gusseted bag that is closed on one end by folding over a stepped-end with pre-applied hotmelt adhesive​
  • Customer fills and seals by reactivating pre-applied hotmelt adhesive to close​
  • Hotmelt adhesive closure extremely effective against product sifting, providing a strong seal for smaller, finer, and denser products​
  • Typically packed and closed on automated equipment





Pinch Bottom Open Mouth

Market Applications

Grain &

Flour

Dairy

Powders

Ingredients &

Seasonings

Rice, Salt, Sugar

Pharmaceuticals

Industrials &

Chemicals

High Performance Barriers, Films, and Coatings Options

Coextruded films

Monolayer films

HDPE, LDPE, LLDPE

3, 5, 7-layer constructions

Specialty films

XF, Nylon, Foil

Coatings

HDPE, UV Varnish, Anti-skid, Matte finishing
